Art Deco Door Plate Entry Mortise Set (l51set)

L51SET  Polished Unlacquered Brass Art Deco Entry Door Set {PICTURED}

LN51SET  Nickel Plated Art Deco Entry Door Set {PICTURED}

LDK51SET  Antique Brass Finish Art Deco Entry Door Set

Great Art Deco Door set.  Available in Polished Unlacquered Brass, Nickel Plated Brass or Antique Brass Finish.

The complete door set includes:

• One Exterior Door Plate
• One Interior Door Plate with Turnlatch Function
• Two Doorknobs with Connecting Spindle
• One Mortise Lock
• One Cylinder Lock with Two Keys
  • Please see our Lock Cylinder Size Chart to select the correct cylinder length for your door.

Measurements:

• Door Plate:  9" tall by 2 5/8" wide.
• Doorknobs:  2 ¼" tall x 1 ¾" wide; each projects 2 7/8".
• Mortise Lock:
  • Backset:  2 ½" (including the thickness of the faceplate).
  • Lock Body:  5 ½" tall by 3 5/8" deep.  13/16" thickness.
  • Lock Face:  7 ½" tall x 1" wide.
  • Catch Plate:  4 7/8" tall by 1 7/8" wide.
  • Measurement from the center of the cylinder hole to the center of the doorknob spindle hole is 3 ¾".
  • Distance from the center of the bolt throw hole to the center of the door knob spindle hole is 2 ½".

Mounting screws are included for each piece of hardware in this set.
