Contemporary Solid Brass Plain Door Plate Entry Set with Lever Handles (l23ent1)

L23ENT1 Solid Brass Door Plate Entry set with Lever Handle Polished Unlacquered Brass

L23ENT1-DK Solid Brass Door Plate Entry set with Lever Handle Antiqued Brass

L23ENT1-OB Solid Brass Door Plate Entry set with Lever Handle Oil Rubbed Bronze

The complete door set includes:

1. Two Doorknob Rosettes
2. Two Lever Handles with connecting spindle
3. Swinging Cylinder Cover
4. Mortise Lock
5. Cylinder Lock: See our Lock Cylinder Size Chart to select the correct cylinder length for your door.
6. Turnlatch

Set Measurements:

Rosettes:   2 1/8" Diameter

Lever handles: Overall size: 4 3/8" long; projects 2 3/8". Diameter of base 3/4".

Lock: Lock body measures 5 1/2" tall by 3 5/8" deep. 13/16" thickness.

Lock face is 1" wide by 7 1/2" long. Backset is 2 1/2", including the thickness of the face plate. Distance from the center of the bolt throw hole to the center of the door knob spindle hole is 2 1/2". Catch plate is 4 7/8" long by 1 7/8".

Cylinder Cover: Measures 2 1/2" long by 1 3/4" wide. Cylinder hole for standard 1.156" (1 5/32") cylinder dia.

Turnlatch:  Square shaft measures 3/16" in diameter, and is 7/8" long. Knob measures 1 1/8" tall by 3/4" wide. Backplate measures 2" tall by 1 1/8" wide.
